Motion sealer shrink wrapping machine SW-M350

Suitable for packing thin and long shape objects and products, such as carpet rolls, roofing rolls......convenient and fast, short delays for each cutting and sealing.
  • Standard machine: No
  • Description
    SW-M350 is a fully automated economical side-sealing packaging machine independently developed by our company. Automatic feeding, conveying, bagging, sealing and shrinking can be completed at one time.
    motion sealing and shrinking machine for packing panel
    With high efficiency, automatic film feeding and perforation device, the machine has perfect continuous performance.
    Suitable for products of different heights and widths, manual adjustment of film guide system enables the machine to cover a large range of product size.
    The SW-M350 model also has a tight joint function, which is specially designed for packaging small products. When the size of the package changes, the adjustment is very simple, without changing the mold and bag form.
    Horizontal heat sealing blade for the sealing part vertically driven, constant temperature side sealing device for longitudinal sealing, beautiful sealing effect which is straight and firm.
    Heating sealing and cutting system with constant temperature for various industrial standard shrink films such as POF.
    Handwheel is used to adjust to adapt to products with different packaging specification, increases reliability and easier operation.
    Longitudinal sealing blade performs continuous sealing and cutting action, unlimited product length.
    Continuous and smooth action for sealing and cuttingmake the sealing action.
    Without replacement, very simple operation for maintenance.
    Feeding length control is combined with electric eye detection and timer to accurately control the length of the film, making the shrinkage effect easier to control.
    Two sets of horizontal and vertical photoelectric sensor, which are easy to switch and choose.
    Automatic waste material recycling, helps to do contribution to the environment protection and resource saving.
    side sealer shrink wrapper machine
    shrink oven of the side sealing shrink wrapping machine
    motion sealer shrink wrapper packing long shape products
    Technical Parameter
    Sealing type side sealing
    Power supply 380V/50-60Hz/3phase
    Sealing height ≤200 mm
    Sealing width ≤250 mm
    Product size width+height≤300mm
    Product length unlimited
    Packing capacity upon product's length
    Film type center-folded polyolefin (POF) film or polyethylene(PE)film
    Max film roll dimension 300mm(width) x 280mm(outer diameter)
    Power consumption 10.5kw
    Heat tunnel conveyor chains with silicon coated rods
    Air pressure ≤0.5MPa
    Sealing system Special durable alloyed sealing knife with anti-stick Teflon coats
    Weight 600kg
